The SUNON EE80251B1-0000-G99 is a 12V DC brushless cooling fan rated at approximately 0.15A, with 80×80×25mm dimensions, ball bearing construction, and a 3-wire connection.
Full Description
The SUNON EE80251B1-0000-G99 is a DC brushless axial cooling fan designed for computers, electronic equipment, servers, and other cooling applications.
It operates at 12V DC with a published current of approximately 0.145A, which can be rounded to 0.15A for a store listing. The documented dimensions are 80×80×25mm. The fan uses a ball bearing and a 3-wire connection, with speed-sensing functionality. Published specifications indicate approximately 3200 RPM and around 41 CFM airflow.
Technical Specifications
| Specification |
Details |
| Brand |
SUNON |
| Model |
EE80251B1-0000-G99 |
| Fan Type |
DC Brushless Axial Fan |
| Operating Voltage |
12V DC |
| Current |
Approx. 0.15A |
| Power |
Approx. 1.7W |
| Documented Dimensions |
80 × 80 × 25 mm |
| Bearing Type |
Ball Bearing |
| Wires |
3-Wire |
| Speed |
Approx. 3200 RPM |
| Airflow |
Approx. 41 CFM |
| Noise |
Approx. 33 dBA |
| Feature |
Speed Sensor / Tach |
| Restart Function |
Auto Restart |
| Color |
Black |
Product Applications
- Computer cooling.
- Server cooling.
- Electronic equipment cooling.
- Networking equipment.
- Communication equipment.
- Ventilation and cooling systems.
- Replacement cooling fan applications.
- Electronics projects.
